Coupled Natural Circulation Loops Updated

I previously made about three years ago two posts about coupled natural circulation loops. These were the results of initial investigations and badly incomplete. This new post brings a degree of completion to those analyses. The original two posts can be discarded.

I have finally pushed through the analysis of two configurations of coupled natural circulation loops; (1) the energy source and energy sink are represented by constant-temperature heat reservoirs and, (2) the energy source is a constant-temperature energy reservoir and the sink is represented by a heat exchanger. The second is a little more representative of physical-domain applications. Additional initial investigations of the most general case having heat exchangers at both the source and sink indicate an almost intractable algebra problem.

These more nearly complete analyses give the temperature distributions interior to the systems in terms of the boundary conditions, as it should. Systems of four equations for the four unknown interior temperatures that requires iterative solution for applications is obtained.

The nomenclature is somewhat complex and the algebra, while straightforward, is tedious.

A file in which the analyses are summarized is NewSimple2Loops07.

I think these results have not appeared in the literature. All comments on the correctness of the results will be appreciated.

February 16, 2016 Posted by | Uncategorized | Leave a comment

Climate is not the Average of Weather

The climate at a location is fundamentally determined by the radiative energy output of the Sun, the relationships between the geometry of the earth, the geometry of the revolution of the earth around the Sun ( the yearly cycle ), the relationship between Earth’s axis of rotation and the plane of Earth’s orbit ( the seasons ), and the rotation of the earth about its axis ( the daily cycle ).

The climate at a location is determined to first order by these factors and the latitude and altitude of the location. The climate also can be influenced by significant, more-or-less thermally stable, bodies of liquid or solid water, primarily near the oceans but including also other large bodies of liquid or solid water.

Meso-scale ( larger than local, smaller than global ) topology of Earth’s surface can also affect local climate. Mountain ranges that significantly affect specific regions relative to precipitation are an example; rain shadows, monsoon

Weather at a location is the time-varying thermodynamic and hydrodynamic states of the atmosphere. Weather can be viewed as perturbations, deviations from some kind of norm, in the local climate. In this sense, one could argue that climate is some kind of temporal average of the weather at a location. Note, however, the descriptions in the previous three paragraphs of the basic factors that determine the climate at a location. These factors are independent of the temporal variations of the states of the atmosphere.

The climate at a location is not determined by the weather. Local climate is determined by factors outside the domain of the states of the atmosphere.

Weather and Climate are Local
Climate and weather are both local and neither is global. There is no need to focus on any aspects of “global climate”: such averages are useless for decision support. Primary focus should be on the advantages and dis-advantages, if any, of the status and changes in local weather. It cannot be over-emphasized the extent to which focus on global-average changes in the “global climate” is mis-guided. Local decision support demands solely local information. It also cannot be over-emphasized that the complete lack of focus on local states is a major failing.

The hour-by-hour, day-to-day, and month-by-month variations in local weather are determined by the effects of the net of the radiative energy into the physical phenomena and processes occurring within and between the thermodynamic and hydrodynamic sub-systems. All phenomena and processes, ( thermodynamic, hydrodynamic, chemical, biological, all ), occurring within the Earth’s systems of interest are driven by this net energy. Basically, weather is the distribution, and internal redistribution, of the energy supplies of sensible and latent thermal energy within Earth’s thermodynamic and hydrodynamic systems.

The solar-system and Earth’s geometric relationships, and local altitude/latitude, are the primary reasons that we can know that the temperature, and the weather in general, at a location will be different, for example, at January and July. The degree of differences between the seasons primarily is determined by the local latitude and altitude. The degree of differences over the seasonal / yearly cycle is a strong function of location. Variations over the seasonal cycle are more or less distinct; the variations are either small or large depending on the location.

Weather and Chaos
Weather is thought to be chaotic. And the numerical solutions of the mathematical models for both weather (NWP) and climate (GCM) are classified as ill-posed, in the sense of  Hadamard, initial-value problems; lack of continuous dependence on the initial data. The average of a chaotic response is itself chaotic. Thus, if climate is the average of weather, then climate is also chaotic. Again, the descriptions of climate given in the first three paragraphs above preclude the chaotic nature of weather being a part of chaotic climate. It is the Earth-Sun geometry and the axis of Earth’s rotation that determines that January and July are easily differentiated. That differentiation is independent of, is not a function of, the chaotic nature of weather.

Chaotic is not random. Chaotic is the antithesis of random. Random fills phase space, whereas temporal chaotic trajectories are limited to the attractor and so by definition, cannot fill phase space. Weather is not random and is not noise; neither pink or white. Especially not white noise which has equal power at all frequencies. Averaging the trajectories from multiple runs of a single GCM, or one or more runs from several GCMs, does not in any way ensure that the so-called noise will be ‘averaged away’. The averaging is instead an averaging of different trajectories. Additionally, there is no way to ensure that the different trajectories are associated with ‘an attractor’ for the real-world case of spatio-temporal chaotic response, which is the case of finite-difference approximations to partial differential equations.

If it is insisted that climate is the average of weather, then projections of the climate into future times demands that weather be correctly simulated by mathematical models that are used for the projections. The statement that, Weather is chaotic and can’t be projected with high fidelity to the physical domain, but climate can be, simply makes no sense.

GCM Validation
Validation, fidelity of simulations relative to the physical domain, of GCMs thus firstly requires that the calculations be shown to be correctly simulating the distribution and internal redistribution of the internal variations; that are responsible for the local weather. Validation relative to effects of increasing concentrations of CO2 must then require that the GCMs are correctly simulating how the distribution and internal redistribution of the internal variations have been altered by the increasing concentration of CO2 in the atmosphere. This is a very difficult problem.

A first major difficulty will be in devising and development of procedures and processes that can be used to determine that changes in the phenomena and processes that are responsible for changes in local weather are in fact due primarily or solely to changes in CO2 concentration. A third order delta that will be exceedingly difficult to (1) observe and (2) model and calculate.

The case of extreme weather events requires the same series of accounting if climate change is invoked as the fundamental cause. Extreme weather events are generally very localized. Thus if the invoked driving source of the event is a significant distance away from the observed occurrence, the effects of changes in the composition of the atmosphere are required to be shown to obtain over the distance of the course from the source to the location of occurrence. If the event is a mighty downpour of rain and the source of the rain is said to be the Oceans far away from the location of the downpour, it must be shown that the changes in the composition of the atmosphere are directly related to the fact that the water vapor survived its path from the Oceans to the downpour location, and that the previous composition of the atmosphere would have prevented the water vapor from surviving its journey. Sounds very difficult to me.

Global Metrics are Useless
Global metrics for assessing GCMs fidelity to the real world are of no use whatsoever relative to assessing the correctness of simulations of local weather. The changes in local weather are required for decision support. Additionally, none of the fundamental laws describing weather and climate can be usefully expressed in terms of global quantities. The state of the atmosphere and the state of liquid and solid phases of water, and changes in these states, are determined by local conditions. No physical phenomena and processes, governed by the fundamental natural laws, have been demonstrated to scale with global averages of anything.

The temperature of the atmosphere, which has been chosen to represent changes in climate due to increasing concentrations of CO2 in the atmosphere, on the other hand, is determined by the path of the thermodynamic processes that the atmosphere experiences at the locations of interest. As the initial states are different, and the changes in weather are different, so will the temperature be different.  Again, no dependency on the global-average state.

Climate is local, weather is local. Weather is the variations in local climate. For decision support, the variations in local weather are what must be correctly simulated by GCMs. The models are required to be able to correctly simulate the changes in the weather variations due to changes in the concentration of CO2.

Based on my comment here.

January 14, 2015 Posted by | Uncategorized | 2 Comments

Natural Circulation Loop with Heat Exchanger Boundary Conditions

The basic natural circulation loop case is modeled with heat source and sink. The high and low temperatures for the fluid are expressed in terms of the source and sink temperatures and the characteristics of the heat exchangers. The transient and steady state model equations are developed, the steady state solution presented, the model equations are given in dimensionless form, and the linearized versions of the equations developed.

Additional work is required to finish analyses of the stability of the system.

A file is here.

March 9, 2013 Posted by | Calculation Verification, Code Verification, Verification | Leave a comment

Coupled Natural Circulation Loops

Coupled natural circulation loops (NCLs) have not been much investigated. Single natural circulation loops, on the other hand, have been the subject of experimental, analytical and numerical research for several decades since the early 1950s. The literature is very extensive with investigations continuing to this day. Much of the research has been directed toward various systems of electric power generation by nuclear power plants.

The objectives of the present notes include; (1) development of model equations for steady-state and transient flows in coupled NCLs, (2) giving the steady state solutions for the steady state equations, (3) linearization of the transient equations for use in stability analyses, and (4) incorporation of realistic boundary-condition representations into the model equation systems for coupled NCLs.

The results are distilled to a system of equations that will be used for investigations into the stability of coupled natural circulation loops.

The design of such systems, also an interesting problem, is not addressed here.

I have uploaded a file here.

February 28, 2013 Posted by | Analytical Sensitivity Analysis, Code Verification, Verification | 3 Comments

Moto Road Trip Travel Logs

I have posted travel logs, with photos, for our Moto Road Trips across America here.

January 7, 2013 Posted by | moto touring | Leave a comment

Verify the Methods: Conservation of Water Mass

Professor Pielke Sr. has posted a comment on this paper. The complete paper is available at the URL. The citation for the paper is:

Beate G Liepert and Michael Previdi, 2012: Inter-model variability and biases of the global water cycle in CMIP3 coupled climate models, 2012: Environmental Research Letters Volume 7 Number 1 014006 doi:10.1088/1748-9326/7/1/014006

Observed changes such as increasing global temperatures and the intensification of the global water cycle in the 20th century are robust results of coupled general circulation models (CGCMs). In spite of these successes,model-to-model variability and biases that are small in first order climate responses, however, have considerable implications for climate predictability especially when multi-model means are used. We show that most climate simulations of the 20th and 21st century A2 scenario performed with CMIP3 (Coupled Model Inter-comparison Project Phase 3) models have deficiencies in simulating the global atmospheric moisture balance. Large biases of only a few models (some biases reach the simulated global precipitation changes in the 20th and 21st centuries) affect the multi-model mean global moisture budget. An imbalanced flux of −0.14 Sv exists while the multi-model median imbalance is only −0.02 Sv. Moreover, for most models the detected imbalance changes over time. As a consequence, in 13 of the 18 CMIP3 models examined, global annual mean precipitation exceeds global evaporation, indicating that there should be a ‘leaking’ of moisture from the atmosphere whereas for the remaining five models a ‘flooding’ is implied. Nonetheless, in all models, the actual atmospheric moisture content and its variability correctly increases during the course of the 20th and 21st centuries. These discrepancies therefore imply an unphysical and hence ‘ghost’ sink/source of atmospheric moisture in the models whose atmospheres flood/leak. The ghost source/sink of moisture can also be regarded as atmospheric latent heating/cooling and hence as positive/negative perturbation of the atmospheric energy budget or non-radiative forcing in the range of −1 to +6 W m−2(median +0.1 W m−2). The inter-model variability of the global atmospheric moisture transport from oceans to land areas, which impacts the terrestrial water cycle, is also quite high and ranges from 0.26 to 1.78 Sv. In the 21st century this transport to land increases by about 5% per century with a model-to-model range from 1 to 13%. We suggest that this variability is weakly correlated to the land–sea contrast in air temperature change of these models. Spatially heterogeneous forcings such as aerosols contribute to the variability in moisture transport, at least in one model. The polewards shifts of dry zones in climate simulations of the 21st century are also assessed. It is shown that the multi-model means of the two subsets of models with negative and positive imbalances in the atmospheric moisture budget produce spatial variability in the dry zone positions similar in size to the spatial shifts expected from 21st century global warming. Thus, the selection of models also affects the multi-model mean dry zone extension. In general, we caution the use of multi-model means of E − P fields and suggest self-consistency tests for climate models.

Clearly the GCMs considered in the paper do not conserve water mass, where water means the phases of water. The ‘leaking’ and ‘flooding’ are nothing more or less than sinks and sources for water due to lack of conservation of mass for these aspects of the numerical solution methods.

Verify the methods.

January 14, 2012 Posted by | Verification | 1 Comment

More on Entropy, MEP, and Climate . . . and more

HISASHI OZAWA AND ATSUMU OHMURA Thermodynamics of a Global-Mean State of the Atmosphere—A State of Maximum Entropy Increase


Vertical heat transport through thermal convection of the earth’s atmosphere is investigated from a thermo- dynamic viewpoint. The postulate for convection considered here is that the global-mean state of the atmosphere is stabilized at a state of maximum entropy increase in a whole system through convective transport of sensible and latent heat from the earth’s surface into outer space. Results of an investigation using a simple vertical gray atmosphere show the existence of a unique set of vertical distributions of air temperature and of convective and radiative heat fluxes that represents a state of maximum entropy increase and that resembles the present earth. It is suggested that the global-mean state of the atmospheric convection of the earth, and that of other planets, is stabilized so as to increase entropy in the universe at a possible maximum rate.

OLIVIER PAULUIS AND ISAAC M. HELD Entropy Budget of an Atmosphere in Radiative–Convective Equilibrium. Part II: Latent Heat Transport and Moist Processes


In moist convection, atmospheric motions transport water vapor from the earth’s surface to the regions where condensation occurs. This transport is associated with three other aspects of convection: the latent heat transport, the expansion work performed by water vapor, and the irreversible entropy production due to diffusion of water vapor and phase changes. An analysis of the thermodynamic transformations of atmospheric water yields what is referred to as the entropy budget of the water substance, providing a quantitative relationship between these three aspects of moist convection. The water vapor transport can be viewed as an imperfect heat engine that produces less mechanical work than the corresponding Carnot cycle because of diffusion of water vapor and irreversible phase changes.

The entropy budget of the water substance provides an alternative method of determining the irreversible entropy production due to phase changes and diffusion of water vapor. This method has the advantage that it does not require explicit knowledge of the relative humidity or of the molecular flux of water vapor for the estimation of the entropy production. Scaling arguments show that the expansion work of water vapor accounts for a small fraction of the work that would be produced in the absence of irreversible moist processes. It is also shown that diffusion of water vapor and irreversible phase changes can be interpreted as the irreversible counterpart to the continuous dehumidification resulting from condensation and precipitation. This leads to a description of moist convection where it acts more as an atmospheric dehumidifier than as a heat engine.

RICHARD GOODY Maximum Entropy Production in Climate Theory


R. D. Lorenz et al. claim that recent data on Mars and Titan show that planetary atmospheres are in unconstrained states of maximum entropy production (MEP). Their model as it applies to Venus, Earth, Mars, and Titan is reexamined, and it is shown that their claim is not justified. This does not necessarily imply that MEP is incorrect, and inapplicable to atmospheres, but it does mean that the difficult and unexplored problem of dynamical constraints on the MEP solution must be understood if it is to be of value for climate research.

Here’s some recent info on the topic.

I ran across this issue of Philosophical Transactions of The Royal Society B: Biological Sciences, May 12, 2010; 365 (1545):
Theme Issue ‘Maximum entropy production in ecological and environmental systems: applications and implications’ compiled and edited by Axel Kleidon, Yadvinder Malhi and Peter M. Cox. doi:10.1098/rstb.2010.0018

Full papers are available at no cost.

This paper:

G Grinstein and R Linsker, “Comments on a derivation and application of the ‘maximum entropy production’ principle” 2007 J. Phys. A: Math. Theor. 40 9717. doi:10.1088/1751-8113/40/31/N01

reports errors in these recent papers by Dewar:

Dewar R 2003. “Information theory explanation of the fluctuation theorem, maximum entropy production and self-organized criticality in non-equilibrium stationary states” J. Phys. A: Math. Gen. 36 631. doi: 10.1088/0305-4470/36/3/303

Dewar R C 2005, “Maximum entropy production and the fluctuation theorem” J. Phys. A: Math. Gen. 38 L371. doi: 10.1088/0305-4470/38/21/L01

Finally, additional papers here. And even more here.

January 13, 2012 Posted by | Uncategorized | 6 Comments

Moto Road Trip Photos: 2008, 2010, and 2011

Moto Road Trip 2008

Moto Road Trip 2010

Moto Road Trip 2011

October 20, 2011 Posted by | moto touring | 5 Comments

Pioneer Mountains Montana

Pioneer Mountains Montana

Pioneer Mountains Montana

October 20, 2011 Posted by | moto touring | Leave a comment

Sunset Bay Oregon Coast

Sunset Bay Oregon Coast

Sunset Bay Oregon Coast

October 20, 2011 Posted by | moto touring | | 1 Comment
